Incoloy 825 Plate
Check Dimension and Sizes of ASTM B424 UNS N08825 Coil & Alloy 825 Sheet, View Nickel 825 Strips price per KG in India
Incoloy 825 Plate is a nickel iron chromium alloy with accompaniments of molybdenum, copper and titanium. This nickel steel alloy's biochemical arrangement is intended to provide excellent resistance too many corrosive surroundings. It is comparable to Nickel Alloy 825 Strip but has better resistance to aqueous corrosion.
Alloy 825 Sheet is also an austenitic nickel iron chromium alloy with accompaniments of molybdenum, copper and titanium. It was industrialized to deliver excellent resistance too many corrosive surroundings, both rusting and plummeting.
Nickel 825 Strip is a nickel iron chromium molybdenum copper covering alloy for use in exceptionally corrosive situations. The nickel gratified of this alloy makes it resistant to chloride ion pressure corrosion fast. Similarly if we talk about ASTM B424 UNS N08825 Coil this products so there are many features of this product or we can say it contains a lot of characteristics such as it defense heat or temperature which is almost up to 60 Degree C and be above as well. Inconel 825 Plate display good machinability and have outstanding weld ability features with or without the count of filler metals, all these products are manufacture in different sizes and shapes with high quality material as according to the demand and instruction of valuable clients in affordable price and supply not only in India but all around the world.
Incoloy 825 Plate
Alloy 825 Sheet
Nickel 825 Strip
Stockist of ASTM B409 Incoloy 825 Shim Sheet, Check Incoloy 825 Foil Price Per Foot, Call us to Get Available size of Nickel Alloy 825 Strip.
Alloy 825 Sheet is also an austenitic nickel iron chromium alloy with accompaniments of molybdenum, copper and titanium. It was industrialized to deliver excellent resistance too many corrosive surroundings, both rusting and plummeting. Alloy 825 Incoloy Clad Plate is a nickel iron chromium alloy with accompaniments of molybdenum, copper and titanium. Alloy 825 Plate has outstanding resistance to both reducing and oxidizing acids. Tarang Steel is leading Incoloy 825 Plate manufacturers in India. View updated ASTM B424 Alloy 825 Plate price list. We are leading Nickel Alloy 825 Coil & Inconel 825 Plate suppliers in more than 35 countries
Incoloy 825 Steel Coil is used in decent temperatures for about 1020 Degree F these coils also has decent mechanical as well as chemical properties from low to high or even extreme temperatures, where conservative machining methods used for iron based alloys may be used.
Table of Content
- What are the characteristics of Incoloy 825 Plate?
- Spec Chart of 2.4858 Alloy 825 Plate
- Incoloy Alloy 825 Sheet Price List
- Available Types of Nickel 825 Plate
- Equivalent Grade Designations Alloy Incoloy 825 Sheet
- Nickel Alloy 825 Plate Stockholder
- Melting Range of ASTM B424 Alloy 825 Plate
- Chemical Composition Standard of Alloy 825 Plate
- ASTM B409 Incoloy 825 Sheet Mechanical Properties Table
- Equivalent material grade of Nickel Alloy 825 Plate
- Stress-Corrosion Cracking Resistance of Alloy 825 Inconel Plate
- Size Chart of Nickel 825 Plate
- Incoloy Alloy 825 Plate Dimensions
- 825 Incoloy Plate Weight Chart
- UNS N08825 Plate Stock List
Incoloy 825 plate
- Good resistance to stress-corrosion cracking
- Excellent resistance to reducing and oxidizing acids
- Permission for pressure-vessel use at wall temperatures up to 800°F
- Very resistant to sulfuric and phosphoric acids
The hot-working range for Alloy 825 Inconel Plate is 1600 to 2150°F (870 to 1180°C). For optimum corrosion resistance, final hot working of Alloy 825 UNS N08825 Hot Rolled Plate should be done at temperatures between 1600 and 1800°F (870 and 980°C).
| Thickness of Nickel Alloy 825 Plate | 0.3 to 1200 mm or as required |
|---|---|
| Incoloy 825 Plate Length | 0-12mm or as required |
| Width of Incoloy 825 UNS N08825 Plate | 0-2500mm or as required |
| Nickel 825 Plate Process | Hot/ Cold Rolled |
| Surface Finish of 825 Incoloy Plate | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled Incoloy 825 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Other Relevant Information of Incoloy 825 Plate for buyers
| Incoloy 825 Plate, Sheet and Strip |
ASTM B 168/ASME SB 168, ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
|---|---|
| Availability of Incoloy 825 Foil sizes |
Thickness : 8-100 microns (0.00031-0.004 in) Width: Up to 500 mm (19.5 in) Weight (in rolls) : Up to 50 kg (110 lb); e.g. approxi- mately 1400 m at 8 microns and ap- proximately 112 m at 100 microns. |
| Standard Incoloy 825 Plate & Sheet Sizes |
1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm
|
| 825 Incoloy Plate Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard Incoloy 825 Sheet suppliers |
| Price of Incoloy 825 Plate | ASTM B443 Incoloy 825 Plate Price in India (INR) | Nickel 825 Plate Price in USD | Alloy 825 Plate Price in UAE Dirham |
|---|---|---|---|
| INCOLOY ALLOY 825 HOT ROLLED PLATE (NI-41.8%, CR-23.2%, MO-3.20% FE-27.5%) 2000MM X 6000MM X 10MM THICK | INR 1,418 | $19.10 | 70.16 UAE Dirham |
| CLAD PLATES IN GRADE AP X-60 PSL -2 (BASE METAL)+INCOLOY 825 OF API 5LD GRADE LC2242: UNS NO. : NO8825 DIMESION NOMINAL | INR 515 | $6.94 | 25.48 UAE Dirham |
| INCOLOY ALLOY 825 HOT ROLLED PLATE (NI-41.8%, CR-23.2%, MO-3.20% FE-27.5%) 2000MM X 6000MM X 10MM THICK | INR 1,411 | $19.01 | 69.81 UAE Dirham |
| CLAD PLATES - SA265 (SA 516 GR.70 + INCOLOY 825) SIZE: LENGTH: 8250 X WIDTH: 2500 X THK: (14.00 + 3.00)MM | INR 365 | $4.92 | 18.06 UAE Dirham |
Alloy Incoloy 825 Shim Stock
ASTM B424 Alloy 825 Perforated Sheet
BS 3073NA16 Coil
VdTüV 432 Chequered Plate
19.1mm ASME SB424 Incoloy 825 Plate
Incoloy 825 Din 2.4858 Cold Rolled Sheet
Alloy 825 Nickel Clad Plate
UNS N08825 Incoloy 825 Foil
Incoloy 825 Nickel Alloy Cold Rolled Plate
ASTM B424 Incoloy 825 Sheet
Alloy Incoloy 825 Strip Tape
ASTM B424 Alloy 825 Sheet
2.4858 Incoloy 825 Hot Rolled Plate
Incoloy UNS N08825 0.4mm thick x 500mmx500mm Sheet
Alloy 825 0.4mm thick x 500mmx500mm Plate
DIN 17750 Shim Sheet
BS 3072NA16 Foil
Alloy Incoloy 825 Coil
UNS N08825 Incoloy 825 Chequered Plate
ASTM B906 Alloy 825 Strip
ISO 6208 Perforated Sheet
ASTM B424 Alloy 825 Strip
Inconel Alloy 825 Checker Plate
825 Inconel Plate
825 Inconel Shim Sheet
Incoloy Alloy 825 0.5mm thick x 250mmx250mm Plate
Incoloy 825 Superalloy Mesh Plate
UNS N08825 Plate
2.4858 Incoloy 825 Coil
Incoloy 825 Alloy Strip
Inconel 825 Foil
SB424 Alloy 825 Polished Plate
Alloy 825 UNS N08825 Hot Rolled Plate
Alloy 825 Nickel Cold Rolled Plate
UNS N08825 Incoloy 825 Plate
ASTM B424 825 Incoloy strip
Alloy 825 Incoloy Clad Plate wholesaler in Mumbai. Ready Stock of 825 Incoloy Shim, Trader of Incoloy Alloy 825 Flat Plate, Importer of ASME SB409 Incoloy 825 Plate.
| UNS: | N08825 |
| Specifications: | ASTM B424 |
| international Specifications: | BS 3072NA16, BS 3073NA16, ASTM B906, DIN 17750, ISO 6208, VdTüV 432 |
| Incoloy 825 Chequered Plate | Nickel Alloy 825 Quarto Plate |
| Incoloy 825 din 2.4858 Clad Plate | Incoloy 825 ASTM B424 Tisco Plate |
| Alloy 825 Chequer Plate | Incoloy Alloy 825 Tread Plate |
| Incoloy 825 ASTM B424 Checker Plate | 825 Incoloy Polished Plate |
| Incoloy Alloy 825 Plate Mirror Finish | Incoloy 825 din 2.4858 Chequered Plate |
| 825 Incoloy Plate Brushed Finish | Incoloy 825 Hot Rolled Sheet |
| Incoloy 825 din 2.4858 10mm Plate | Incoloy 825 ASTM B424 Cold Rolled Sheet |
| Incoloy 825 1/4 Inch Plate | Incoloy 825 UNS N08825 Perforated Sheet |
| Incoloy 825 UNS N08825 Plate | Nickel 825 Rolling Plate |
| Nickel Alloy 825 Hot Rolled Plate | 825 Incoloy Perforated Plate |
| Nickel 825 Cold Rolled Plate | ASTM B424 UNS N08825 Bbq Plate |
| 825 Incoloy Plate 2b Finish | Incoloy 825 din 2.4858 Diamond Plate |
| ASTM B424 UNS N08825 Plate Mill Finish | Alloy 825 Thin Plate |
| Incoloy 825 ASTM B424 Custom Cut Plate | Nickel 825 Sheet |
| Incoloy 825 UNS N08825 Checkered Plate | Incoloy 825 Laser Cut Plate |
| Nickel 825 Embossed Plate | Incoloy 825 UNS N08825 Plasma Cutting Plate |
| Alloy 825 UNS N08825 Hot Rolled Plate | Incoloy 825 Nickel Alloy Slitting Coil |
| Incoloy 825 Din 2.4858 Shim Sheet | Incoloy UNS No 8825 4mm Thick Plate |
| Alloy 825 Nickel Cold Rolled Plate | Alloy 825 Incoloy Flat Plate |
| Inconel 825 Foil | Incoloy 825 Nickel Clad Plate |
| Incoloy 8825 Polish Plate | Inconel 825 sheet |
| Alloy 825 Inconel Strip Tape | Incoloy UNS No 8825 4mm Thick Plate |
Supplier of Alloy Incoloy 825 Sheet, Incoloy 825 Steel Coil, 2.4858 Incoloy 825 Foil stockist in Mumbai, India, check Incoloy Alloy 825 Strip Price in India, Buy high quality JIS NCF 825 Plate.
|
Incoloy 825 Melting Point
|
|
1370-1400℃
|
Leading Stockholder of Incoloy Alloy 825 Plate
ASTM B424 Alloy 825 Sheet
Incoloy 825 Hot Rolled Plates
Incoloy Alloy 825 Cold Drawn Coil
Incoloy DIN 2.4858 Coil
Incoloy 825 UNS N08825 Hot Rolled Plate importer in India, Special price for 825 Incoloy Strip Tape, Incoloy 825 Plate material dealer. Mirror finish ASME SB409 Incoloy N08825 Cold Rolled Plate suppliers in India. 825 Alloy Polished Plate and JIS NCF Incoloy 825 Plate Stockholder.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
| Alloy Tested as U-Bend Samples | ||||
|---|---|---|---|---|
| Test Solution | Alloy 316 | SSC-6MO | Alloy 825 | Alloy 625 |
| 42% Magnesium Chloride (Boiling) | Fail | Mixed | Mixed | Resist |
| 33% Lithium Chloride (Boiling) | Fail | Resist | Resist | Resist |
| 26% Sodium Chloride (Boiling) | Fail | Resist | Resist | Resist |
|
Size (in inches)
|
Size (in mm)
|
|---|---|
|
.125"
|
3.18mm
|
|
.134"
|
3.40mm
|
|
.156"
|
3.96mm
|
|
.187"
|
4.75mm
|
|
.250"
|
6.35mm
|
|
.312"
|
7.92mm
|
|
.375"
|
9.53mm
|
|
.500"
|
12.7mm
|
|
.600"
|
15.9mm
|
|
.750"
|
19.1mm
|
|
.875"
|
22.2mm
|
|
1"
|
25.4mm
|
|
1.125"
|
28.6mm
|
|
1.250"
|
31.8mm
|
|
1.500"
|
38.1mm
|
|
1.750"
|
44.5mm
|
|
2"
|
50.8mm
|
|
2.500"
|
63.5mm
|
|
3"
|
76.2mm
|
Incoloy 825 Plate Imperial Dimensions
| Plate Surface finish | Gauge (in) | Width (max in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished plate (not brushed) | 11–24 | 60 |
| Temper rolled plate Mexinox only | 13–29 | 48 |
Alloy 825 Plate Metric Dimensions
| Plate Surface finish | Thickness (mm) | Width (max mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed plate | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled plate | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
| Alloy | Product form | Dimension |
|---|---|---|
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard | 0.40x5 mm x coil, 0.016 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard rolled, special temper | 0.40x25 mm x coil, 0.007 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard | 0.50x5 mm x coil, 0.02 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, bright anneal, clean spool | 0.60x5 mm x spool, 0.02 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard rolled, special temper | 0.60x25 mm x coil, 0.011 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 0.5x914.4 mm x coil, 3.587 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 0.6x1219 mm x coil, 5.95 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed, bellows quality | 0.7x1219 mm x coil, 6.70 kg/m |
| INCOLOY 825 (42 Ni /22Cr/3 Mo) | Sheet; cold rolled, annealed | 0.8x1220 mm x coil, 7.76 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, annealed | 1.0x1219 mm x coil, 9.5 kg/m |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, pickled, annealed | 1.6x1200x3000 mm, 46.4 kg/pc |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, pickled, annealed | 2.0x1200x3000 mm, 60.15 kg/pc |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Sheet; cold rolled, soft annealed,descaled, sheared | 3.0x1200x3000 mm, 88.5 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Plate; hot rolled, soft annealed, descaled, sheared | 4.0x2440x6000 mm, 482 kg/pc |
| INCOLOY 825 (42 Ni/22 Cr/3 Mo) | Plate; hot rolled, descaled, annealed | 5.0x2000x6000 mm, 539 kg/pc |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Strip; cold rolled, hard | 1.0x5 mm x coil, 0.039 kg/m |
| ALLOY 825 (42 Ni/22 Cr/3 Mo) | Plate; hot rolled, descaled, annealed | 18.0x260x260 mm, 9.9 kg/pc |
| Thickness | Alloy | Plate Weight per Unit Area | Density |
|---|---|---|---|
| 3/16 inches | Incoloy 825 | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | Incoloy 825 | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | Incoloy 825 | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | Incoloy 825 | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | Incoloy 825 | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | Incoloy 825 | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | Incoloy 825 | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | Incoloy 825 | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | Incoloy 825 | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | Incoloy 825 | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | Incoloy 825 | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | Incoloy 825 | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | Incoloy 825 | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | Incoloy 825 | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | Incoloy 825 | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | Incoloy 825 | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
