Inconel 600 Plate is manufactured using high quality material, the substantial which is used to produce this industrialized product is patterned under a huge procedure to satisfy the consumers and retailer demands, and with respect to standard quality of material we also manufacture this industrial products which is Inconel 600 Plate as according to the need of respectable consumer in different dimensions, outlines and strategies. Inconel 600 plates can be recycled at a very high heats up to 2000 degree F whereas if we talk about Alloy 600 Sheet so it can also be used at a very high temperature same as the heat of Inconel 600 plates which is 2000 F but just a one minor difference between both of them is Alloy 600 sheets are non-magnetic and enthusiastically weld able in its features.
Inconel 600 plate
ASTM B168 Alloy 600 Sheet
Inconel 600 Strip
Similarly if we talk about Nickel 600 Strip so it is also a nickel chromium alloy rummage-sale for applications that need equally corrosion and resistance to the maximum of temperatures. The great nickel material in 600 is what allows it to recall substantial resistance under plummeting conditions.
Our Tarang Steelis a manufacturer of ASTM B443 UNS N06600 Strip this industrial product with some standards because we are major with massive inventory of not only the industrial products which we have deliberated above but we also produce Alloy 600 UNS N06600 Shim Sheet with standard and outstanding material under the observation of superior staff. We have circulation midpoints in many of the country particularly in UK, China and exactly in India and everywhere in the world, with a deals and service center system close to our clients.
Inconel 600 plate
Inconel 2.4816 Foil is a non-magnetic austenitic alloy with an excessive nickel content. This compound can be used in clarifications of magnesium chloride in view of its unsettled resistance from chloride density for fast oxidization it also has strange advantage at working high temperatures which can be up to 2000 F.
Alloy 600 Plate Thickness | 0.3 to 1200 mm or as required |
---|---|
UNS N06600 Plate Process | Hot/ Cold Rolled |
Inconel 600 Plate Length | 0-12mm or as required |
ASTM B168 Alloy 600 Plate Width | 0-2500mm or as required |
ASTM B168 Inconel 600 Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled Inconel 600 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Inconel 600 Plate, Sheet and Strip |
Inconel 600 Plate, Sheet and Strip - ASTM B 168/ASME SB 168, ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
---|---|
Standard Inconel 600 Plate & Sheet Sizes |
1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm
|
ASME SB168 Inconel 600 Plate Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard Inconel 600 Sheet suppliers |
Availability of Inconel 600 Foil sizes | Thickness : 8-100 microns (0.00031-0.004 in) Width: Up to 500 mm (19.5 in) Weight (in rolls) : Up to 50 kg (110 lb); e.g. approxi- mately 1400 m at 8 microns and ap- proximately 112 m at 100 microns. |
Profiling |
To provide a full profiling service in India we use numerous profiling methods including:
|
Tolerances of width and thickness |
|
Inconel 600 plate standards and approvals |
|
Plasma profiles | As per customer's drawings |
Value added services for Inconel 600 Plate | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
Value added services for Inconel 600 Coil |
|
Manufacturer & exporter of |
|
Inconel 600 plate Origin | Indian Origin, European Origin, Japanese Origin |
Packing of Inconel 600 plate | Bundles with waterproof cloth outside or plywood box |
Test | UT, SGS testing, TUV etc |
Price of Inconel 600 Plate | ASTM B443 Inconel 600 Plate Price in India (INR) | Inconel 600 UNS N06600 Plate Price in USD | Alloy 600 Plate Price in UAE Dirham |
---|---|---|---|
INCONEL ALLOY 600 PLATE 70MM THK AS PER SB 168 UNS NO6600, 2400MM X 2400MM LONG(HOT ROLLED) | INR 1,514 | $1.54 | 5.64 UAE Dirham |
INCONEL ALLOY 600(UNS N06600)HOT ROLLED PLATE ANNEALED,DESCALED.ASTM B168/ASME SB168 (NICKEL ALLOYS)65MM THK X 900MM X 1 | INR 1,658 | $22.28 | 81.85 UAE Dirham |
INCONEL PLATE 12MM THK (ALLOY 600) 565MM X565MM | INR 60,285 | $810.25 | 2976.02 UAE Dirham |
INCONEL PLATE 12MM THK (ALLOY 600) 815MM X815MM (NICKEL ALLOYS) | INR 126,029 | $1693.88 | 6221.54 UAE Dirham |
UNS: |
N06600 |
Specifications: |
AMS 5540, ASTM B168 |
international Specifications: |
DIN 17750, DIN 17754 WERKSTOFF Nr 2.4816 TÜV 305 AFNOR-NC 15 Fe, BS 3072-3076 (NA14) DIN 17742 |
Inconel 600 Chequered Plate | Alloy 600 Quarto Plate |
Inconel Alloy 600 Clad Plate | Inconel UNS N06600 Tisco Plate |
Inconel WERKSTOFF NR. 2.4816 Chequer Plate | ASTM B168 Alloy 600 Tread Plate |
Inconel UNS N06600 Checker Plate | ASME SB168 Inconel 600 Polished Plate |
ASTM B168 Alloy 600 Plate Mirror Finish | Inconel DIN NR. 2.4816 Chequered Plate |
ASME SB168 Inconel 600 Plate Brushed Finish | 600 Inconel Hot Rolled Sheet |
Inconel DIN NR. 2.4816 10mm Plate | ASME SB168 Alloy 600 Cold Rolled Sheet |
600 Inconel 1/4 Inch Plate | WNR 2.4816 Perforated Sheet |
ASTM B168 Alloy 600 Plate | UNS N06600 Rolling Plate |
Alloy 600 Hot Rolled Plate | ASTM B168 Inconel 600 Perforated Plate |
UNS N06600 Cold Rolled Plate | ASME SB168 UNS N06600 Bbq Plate |
ASTM B168 Inconel 600 Plate 2b Finish | Inconel Alloy 600 Diamond Plate |
ASME SB168 UNS N06600 Plate Mill Finish | Inconel WERKSTOFF NR. 2.4816 Thin Plate |
ASME SB168 Alloy 600 Custom Cut Plate | Inconel 600 UNS N06600 Sheet |
WNR 2.4816 Checkered Plate | Inconel 600 Laser Cut Plate |
Inconel 600 UNS N06600 Embossed Plate | ASTM B168 Alloy 600 Plasma Cutting Plate |
UNS N06600 Inconel 600 Plate density
|
8.1 g/cm cube
|
ASTM B168 Alloy 600 Plate Imperial Dimensions
Plate Surface finish | Gauge (in) | Width (max in) |
---|---|---|
2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
BA Mexinox only | 18–28 | 48 |
Polished plate (not brushed) | 11–24 | 60 |
Temper rolled plate Mexinox only | 13–29 | 48 |
ASTM B168 600 Alloy Plate Metric Dimensions
Plate Surface finish | Thickness (mm) | Width (max mm) |
---|---|---|
2B – Cold rolled, heat treated, pickled, skin passed plate | 0.25–8.0 | 2032 |
2D – Cold rolled, heat treated, pickled plate | 0.4–6.35 | 1524 |
2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
2H – Work hardened plate | 0.4–6.35 | 1524 |
Polished, brushed plate | 0.5–4.0 | 1524 |
Inconel 600 | Inconel 625 |
---|---|
Inconel 600 contains minimum nickel content of 72% | Inconel 625 contains minimum nickel content of 52% |
Melting Point of Alloy 600 is 1413 °C | Melting Point of Alloy 625 is 1350 °C |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Size (in inches)
|
Size (in mm)
|
---|---|
.125"
|
3.18mm
|
.134"
|
3.40mm
|
.156"
|
3.96mm
|
.187"
|
4.75mm
|
.250"
|
6.35mm
|
.312"
|
7.92mm
|
.375"
|
9.53mm
|
.500"
|
12.7mm
|
.600"
|
15.9mm
|
.750"
|
19.1mm
|
.875"
|
22.2mm
|
1"
|
25.4mm
|
1.125"
|
28.6mm
|
1.250"
|
31.8mm
|
1.500"
|
38.1mm
|
1.750"
|
44.5mm
|
2"
|
50.8mm
|
2.500"
|
63.5mm
|
3"
|
76.2mm
|
Alloy | Product form | Dimension |
---|---|---|
INCONEL 600 (75 Ni/16 Cr) | Strip; cold rolled, annealed | 0.10x150 mm x coil, 0.12 kg/m |
ALLOY 600 (75 Ni/16 Cr) | Strip; cold rolled, annealed | 0.40x200 mm x coil, 0.7 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 0.4x914.4 mm x coil, 3.03 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 0.5x1000 mm x coil, 4.14 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 0.7x1000x2000 mm, 13.25 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 0.8x1219 mm x coil, 8.1 kg/m |
ALLOY 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 1.0x1220 mm x coil, 10.10 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 1.2x1200x3000 mm, 37.8 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, pickled, annealed | 1.6x1220x3600 mm, 59 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed | 2.0x1200x3000 mm, 62 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Sheet; cold rolled, annealed, pickled | 2.5x1200x3000 mm, 76 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Sheet; cold rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 3.0x1220x3000 mm, 92 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, annealed | 4.0x1200x3000 mm, 122 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, annealed | 5.0x2400x6000 mm, 606 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 6.0x2440x6000 mm, 746 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Plate; hot rolled, descaled, annealed | 8.0x2000x4000 mm, 564 kg/pce |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 10.0x2000x4000 mm, 726 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 12.0x2000x3000 mm, 616 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Plate; hot rolled, annealed | 20.0x915x1235 mm, 193 kg/pc |
Thickness | Alloy | Plate Weight per Unit Area | Density |
---|---|---|---|
3/16 inches | Inconel 600 | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1/4 inches | Inconel 600 | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
3/8 inches | Inconel 600 | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1/2 inches | Inconel 600 | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
5/8 inches | Inconel 600 | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
3/4 inches | Inconel 600 | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
7/8 inches | Inconel 600 | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 inches | Inconel 600 | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 1/4 inches | Inconel 600 | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 1/2 inches | Inconel 600 | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 3/4 inches | Inconel 600 | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 inches | Inconel 600 | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 1/4 inches | Inconel 600 | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 1/2 inches | Inconel 600 | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 3/4 inches | Inconel 600 | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
3 inches | Inconel 600 | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
