The specified astm b366 wpncmc fittings cover nickel and nickel alloyed fittings which can be shaped by performing operations such as pressing, extruding, piercing, upsetting, hammering, rolling, bending, or fusion welding. The astm b366 wpncmc gr 1 elbow is one of the more widely used and more popular fittings and is known to offer flexibility to change the pipe direction.
ASTM B366 WPNCMC Fittings
ASME SB366 WPNCMC Reducer
ASTM B366 WPNCMC gr 1 Elbow
Apart from being used as a cover for the end of a pipe, the astm b366 grade wpnicmc pipe cap can be used as piping headers for connections in the future. Used in conjunction with a lap joint flange, the astm b366 cl wpncmc stub end basically considered to be a part of a flange.
Both the Concentric & Eccentric asme sb366 wpnicmc reducer is known to change the size of a pipe in a piping system. A chemical and product analyses is typically conducted on the astm b366 gr wpncmc-s pipe fittings to check if these fittings conform to the specification. b366 gr.wpncmc buttweld fittings are a kind of a weldable pipe fitting which permits a change in the direction of flow, to branch off or to reduce the size of the pipe.
ASME SB366-WPNCMC Pipe Fittings size | ASTM B366 WPNCMC Seamless Butt Weld Fittings: 1/2" - 10" ASTM B366 GRADE WPNCMC Welded Butt Weld Fittings: 1/2" - 48" |
---|---|
B366 WPNCMC Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
SB366 WPNCMC Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
ASTM B366 WPNCMC Pipe fittings Types |
|
ASTM B366 WPNCMC FittingsType | DN15-DN1200 |
ASME SB366 GRADE WPNCMC Buttweld Fitting Connection | Welding |
Bending Radius | R= 2D, 6D, 1D, 5D, 8D, 3D, 10D or Custom ASME SB366 WPNCMC Pipe Fitting |
Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366-WPNCMC Buttweld Fitting |
B366 gr WPNCMC Elbows | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D . Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
ASTM B366 WPNCMC Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
ASTM B366 WPNCMC Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 |
Nominal Pipe Size | All Fittings | All Fittings | All Fittings | Elbows/ Tees | 180° Return Bends | 180° Return Bends | 180 Deg Return Bends | Reducers | Caps |
---|---|---|---|---|---|---|---|---|---|
NPS | O.D. at Bevel (1), (2) | I.D. at End (1), (3), (4) |
Wall Thickness (3) | Centre-to-End Dimension A,B,C,M | Centre-to-Centre O | Back-to-Face K | Alignment of Ends U | Overall Length H | Overall Length E |
½ to 2½ | 0.06 -0.03 |
0.03 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
3 to 3 ½ | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
4 | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
5 to 8 | 0.09 -0.06 |
0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
10 to 18 | 0.16 -0.12 |
0.12 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
20 to 24 | 0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
26 to 30 | 0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.12 | … | … | … | 0.19 | 0.38 |
32 to 48 | 0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.19 | … | … | … | 0.19 | 0.38 |
ASTM B366 GRADE WPNCMC Fittings | ASTM B366 WPNCMC Pipe Fitting |
ASME SB366 WPNCMC 90 Degree Elbow | ASTM B366-WPNCMC End Cap |
B366 WPNCMC 45 Degree Elbow | ASME SB366 GRADE WPNCMC Buttweld Fitting |
SB366 WPNCMC 1D Elbow | ASME SB366-WPNCMC Short Stub End |
ASME SB366 GRADE WPNCMC Stub End | ASTM B366 GRADE WPNCMC Pipe Cap |
ASME SB366-WPNCMC 3D Elbow | B366 gr WPNCMC End Cap |
ASTM B366 WPNCMC 5D Elbow | B366 gr WPNCMC Reducer |
ASTM B366 GRADE WPNCMC Buttweld Fittings | ASTM B366-WPNCMC Pipe Bend |
B366 WPNCMC Pipe Fittings | SB366 WPNCMC Long Stub End |
ASME SB366 GRADE WPNCMC Eccentric Reducer | SB366 WPNCMC Long Radius Elbow |
Seamless | Welded | |
---|---|---|
End Caps | Upto 24" | |
Elbows | Upto 24" | Upto 42" |
Tees | Upto 24" | Upto 36" |
Reducers | Upto 24" | Upto 48" |
Cross | Upto 8" | Upto 36" |
Return Bends | Upto 8" | |
Swage Nipple | Upto 4" | |
Special Fittings: Piggable Bends, 3D, 5D, 10D etc. Customized Bends, Miter Bends | As per customer drawings and datasheets | |
Thickness | Sch 5, Sch 5s, Sch 10, Sch 10s, Sch 20, Sch 30, Sch 40s, Sch 40, Sch STD, Sch 60, Sch 80s, Sch 100, Sch 120, Sch XS, Sch XXS, Sch 160, upto 50mm in case of welded fittings |
