Being one of the two most commonly utilized titanium alloy grades, the Titanium Grade 5 Round Bar accounts for almost 50% of the titanium-based products, used across the globe. The manufacturing process of the Alloy Grade 5 Flat Bar dictates that these bars be produced by either casting or by using a powder metallurgical or even by hot forming these bars. Although the properties of the Grade 5 Ti.
Titanium Grade 5 Round Bar
Titanium Gr 5 Rod
Ti Grade 5 Flat bar
Alloy Black Bar, as usual, would depend on the chemical composition of the material as well as the thermomechanical process used. Typically alloy grade 5 is used in a soft annealed condition. In its soft annealed condition, the UNS R56400 Titanium Polished Bars capitulates with the best possible combination of properties such as toughness, tensile strength as well as ductility. Stronger than commercially pure titanium grades 1 - 4, the Titanium grade 5 Bar also exhibits properties like the stiffness and thermal properties, which are almost parallel to CP titanium grades.
Titanium Grade 5 Round Bar
In addition to having good fabricability, the Titanium Gr 5 Rod has good weldable properties as well. However, while welding the alloy, certain parameters must be taken into account namely the shielding inert gas used in the process as well as the cooling temperature and cleaning the welded area on the Ti Grade 5 Flat bar in order to optimise its strength and corrosion resistance properties.
Specifications | ASTM B446 / ASTM SB446 |
size | 2-100mm A/F |
---|---|
Square bar size | 4 to 100mm |
Flat bar size | Thickness: 2 -100mm Width: 10 to 500mm |
Round bar size | Diameter: 3-~800mm |
Rectangles Size | 33 x 30mm to 295 x 1066mm |
Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
Section | 3.0 to 12.0mm thickness |
Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
Billet Size | 1/2" to 495mm Diameter |
Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline, Polished |
Condition | Hardened & tempered, annealed |
Technique | Inconel 625 Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
Processing | Bar cutting to 650mm |
Form | Round, Welding Rod, T-Bar, Rod, Precision Ground Bar, Channel Bar, Square, Flat Bar, Blocks, Round Rod, Hollow, Rings, Rectangle, Hex (A/F), Triangle, Threaded, Profiles, Billet, Ingot, I/H Bar, Half Round Bar, Forging etc. |
Price of Titanium Grade 5 Round Bar | Titanium Alloy Gr 5 Round Bar Price in India (INR) | Titanium Alloy Gr 5 Round Bar Price in USD | Titanium Alloy Gr 5 Round Bar Price in UAE Dirham |
---|---|---|---|
TITANIUM ROUND BAR GRADE 5 AMS 4928 BS 3TA11 - 330MM DIA X 1300MM L | INR 4,244 | $57.13 | 209.83 UAE Dirham |
TITANIUM ROUND BAR GRADE 5 AMS 4928 BS 3TA11 - 230MM DIA X 910MM | INR 1,660 | $22.34 | 82.07 UAE Dirham |
TITANIUM ROUND BARS, GRADE 5 TI6AL-4V AMS 4928 1.25 X 12R/L ATIR4505 | INR 3,164 | $42.59 | 156.43 UAE Dirham |
AMS 4911 | AMS 4928 | AMS 4965 |
AMS 4967 | AMS 6930 | AMS 6931 |
AMS-T-9046 (AB-1 6AL4V) | AMS-T-9047 (6AL-4V) | MIL-T-9046 (AB-1 6AL-4V) |
MIL-T-9047 (6AL-4V) | ASTM B348 (Grade 5) | ASTM B265 (Grade 5) |
ASTM F1472 | DMS 1592 | DMS 1570 |
