The most obvious advantage of using various grades of Titanium Flanges as opposed to their more conventionally used steel counterpart is that they have a lower density and therefore are light in weight. Although the metal is light in weight, the Titanium Blind Flange has the ability to withstand elevated temperatures as well as high pressures, especially when involved in piping systems. Typically a blind flange is used to block vessels or a nozzle and hence the activity in the system creates a lot of stress. Since the Titanium RTJ Flange has good tensile strength and toughness properties the metal can be considered as a quintessential part of many systems.
Titanium Flanges
Titanium Alloy Blind Flange
Ti Alloy WNRF Flange
Get Latest Price List of Titanium Spectacle Blind Flange, Leading Titanium RTJ Flange Supplier, Ready stock of Titanium Blind Flange at reasonable cost.
However, it must be noted that while titanium is a metal that is strong, its commercially pure grades i.e. grade 1 - 4 tend to be ductile and are soft, which is why most suppliers across demanding fields would prefer using a titanium based alloy or stainless steel or a carbon steel substitute while choosing flanges for applications. Very commonly, a Titanium Alloy Blind Flange is used to not only test the flow of gas but also liquid through either a pipe or vessel.
Table of Content
- What is Titanium Flange?
- Titanium Steel Alloy Flange Price Per Kg
- Titanium Flanges Standard Specification
- Ti Alloy Pipe Flange Dimensions
- Most popular types of Titanium Flange
- Equivalent Material of Titanium Alloy Flange
- Titanium Alloy Flange Mechanical Properties
- Chemical Compatibility of Alloy Titanium Flange
- Weight Chart Of 80mm (3") Titanium Wrought Alloy Flange
Designed for high pressured applications based in either cold or elevated temperature settings the Titanium WNRF Flange can be identified by their long tapered hub. More often than not, the Ti alloy Buttweld Stub End is used to connect flanges & pipes and are often used in combination of a welding process. The Titanium Spectacle Blind Flange is applied to piping systems in order to permanently separate them.
| Standard | ASTM A213, ASTM A269, ASTM A249 |
| Grade | Titanium Gr2, Gr.5, Gr.7 (UNS R50400), Werkstoff nr.3.7035 |
| Class | 150#, 300#, 825#, 900#, 1500# & 2500# |
| Dimension | ANSI/ASME B16.5, B 16.47 Series A & B, EN-1092, BS4504, BS 10, B16.48, DIN, etc. |
| Size | ½” to 18" |
| Specialize | ASME Flanges, ANSI Flanges, DIN Flanges, BS Flanges, EN Flanges, SORF Flanges, BLRF Flanges, SWRF Flanges, WNRF Flanges, etc |
| Flanges Types | Reducing Flanges, Socket weld Flanges, Weld Neck Flanges, Orifice Flanges, Lap Joint Flanges, Blind Flanges, Slip on Flanges, Threaded Flanges, Plate Flanges, Industrial Flanges, etc |
Specialise in Supplying Titanium WNRF Flange, Titanium Lap Joint Flange available in wider range of sizes, One Stop Shop For Titanium Slip on Flange, Stockholder of Titanium Forged Flanges
| Bore Diameter | Length Through Hub | ||||||||||||||||||
| Nominal Pipe Size | Flange Outside Diameter | Flange Thickness | Hub Dia. At Base | Raised Face Dia. | Hub Dia. At Welding Point | Welding Neck | Slip On | Welding Neck | Slip On | ||||||||||
| in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm |
| 1/2″ | 15 | 3.50 | 88.90 | 0.44 | 11.11 | 1.19 | 30.16 | 1.38 | 34.93 | 0.84 | 21.34 | 0.62 | 15.75 | 0.88 | 22.35 | 1.88 | 47.63 | 0.63 | 15.88 |
| 3/4″ | 20 | 3.88 | 98.43 | 0.50 | 12.70 | 1.50 | 38.10 | 1.69 | 42.86 | 1.05 | 26.67 | 0.82 | 20.83 | 1.09 | 27.69 | 2.06 | 52.39 | 0.63 | 15.88 |
| 1″ | 25 | 4.25 | 107.95 | 0.56 | 14.29 | 1.94 | 49.21 | 2.00 | 50.80 | 1.32 | 33.53 | 1.05 | 26.67 | 1.36 | 34.54 | 2.19 | 55.56 | 0.69 | 17.46 |
| 1-1/4″ | 32 | 4.63 | 117.48 | 0.63 | 15.88 | 2.31 | 58.74 | 2.50 | 63.50 | 1.66 | 42.16 | 1.38 | 35.05 | 1.70 | 43.18 | 2.25 | 57.15 | 0.81 | 20.64 |
| 1-1/2″ | 40 | 5.00 | 127.00 | 0.69 | 17.46 | 2.56 | 65.09 | 2.88 | 73.03 | 1.90 | 48.26 | 1.61 | 40.89 | 1.95 | 49.53 | 2.44 | 61.91 | 0.88 | 22.23 |
| 2″ | 50 | 6.00 | 152.40 | 0.75 | 19.05 | 3.06 | 77.79 | 3.63 | 92.08 | 2.38 | 60.45 | 2.07 | 52.58 | 2.44 | 61.98 | 2.50 | 63.50 | 1.00 | 25.40 |
| 2-1/2″ | 65 | 7.00 | 177.80 | 0.88 | 22.23 | 3.56 | 90.49 | 4.13 | 104.78 | 2.88 | 73.15 | 2.47 | 62.74 | 2.94 | 74.68 | 2.75 | 69.85 | 1.13 | 28.58 |
| 3″ | 80 | 7.50 | 190.50 | 0.94 | 23.81 | 4.25 | 107.95 | 5.00 | 127.00 | 3.50 | 88.90 | 3.07 | 77.98 | 3.57 | 90.68 | 2.75 | 69.85 | 1.19 | 30.16 |
| 3-1/2″ | 90 | 8.50 | 215.90 | 0.94 | 23.81 | 4.81 | 122.24 | 5.50 | 139.70 | 4.00 | 101.60 | 3.55 | 90.17 | 4.07 | 103.38 | 2.81 | 71.44 | 1.25 | 31.75 |
| 4″ | 100 | 9.00 | 228.60 | 0.94 | 23.81 | 5.31 | 134.94 | 6.19 | 157.16 | 4.50 | 114.30 | 4.03 | 102.36 | 4.57 | 116.08 | 3.00 | 76.20 | 1.31 | 33.34 |
| 5″ | 125 | 10.00 | 254.00 | 0.94 | 23.81 | 6.44 | 163.51 | 7.31 | 185.74 | 5.56 | 141.22 | 5.05 | 128.27 | 5.66 | 143.76 | 3.50 | 88.90 | 1.44 | 36.51 |
| 6″ | 150 | 11.00 | 279.40 | 1.00 | 25.40 | 7.56 | 192.09 | 8.50 | 215.90 | 6.63 | 168.40 | 6.07 | 154.18 | 6.72 | 170.69 | 3.50 | 88.90 | 1.56 | 39.69 |
| 8″ | 200 | 13.50 | 342.90 | 1.13 | 28.58 | 9.69 | 246.06 | 10.63 | 269.88 | 8.63 | 219.20 | 7.98 | 202.69 | 8.72 | 221.49 | 4.00 | 101.60 | 1.75 | 44.45 |
| 10″ | 250 | 16.00 | 406.40 | 1.19 | 30.16 | 12.00 | 304.80 | 12.75 | 323.85 | 10.75 | 273.05 | 10.02 | 254.51 | 10.88 | 276.35 | 4.00 | 101.60 | 1.94 | 49.21 |
| 12″ | 300 | 19.00 | 482.60 | 1.25 | 31.75 | 14.38 | 365.13 | 15.00 | 381.00 | 12.75 | 323.85 | 12.00 | 304.80 | 12.88 | 327.15 | 4.50 | 114.30 | 2.19 | 55.56 |
| 14″ | 350 | 21.00 | 533.40 | 1.38 | 34.93 | 15.75 | 400.05 | 16.25 | 412.75 | 14.00 | 355.60 | 13.25 | 336.55 | 14.14 | 359.16 | 5.00 | 127.00 | 2.25 | 57.15 |
| 16″ | 400 | 23.50 | 596.90 | 1.44 | 36.51 | 18.00 | 457.20 | 18.50 | 469.90 | 16.00 | 406.40 | 15.25 | 387.35 | 16.16 | 410.46 | 5.00 | 127.00 | 2.50 | 63.50 |
| 18″ | 450 | 25.00 | 635.00 | 1.56 | 39.69 | 19.88 | 504.83 | 21.00 | 533.40 | 18.00 | 457.20 | 17.25 | 438.15 | 18.18 | 461.77 | 5.50 | 139.70 | 2.69 | 68.26 |
| 20″ | 500 | 27.50 | 698.50 | 1.69 | 42.86 | 22.00 | 558.80 | 23.00 | 584.20 | 20.00 | 508.00 | 19.25 | 488.95 | 20.20 | 513.08 | 5.69 | 144.46 | 2.88 | 73.03 |
| 24″ | 600 | 32.00 | 812.80 | 1.88 | 47.63 | 26.13 | 663.58 | 27.25 | 692.15 | 24.00 | 609.60 | 23.25 | 590.55 | 24.25 | 615.95 | 6.00 | 152.40 | 3.25 | 82.55 |
