Inconel 601 round bar are highly valued for its dimensional accurateness, superior finish, quality, durability and great broad-mindedness. This Inconel 601 round bar are verified on many parameters in order to deliver a flaw free range of our industrial product we take a long procedure which contains a lot of steps under the supervision of some expert and then any signal is individually ready to pass out from our Tarang Steel branded side with the help of our hardworking team of professionals, which is a huge reason or cause of satisfaction of our consumers and regulars, we become capable enough to proposal our respected clients with high superiority Inconel 601 Round Bar at market leading prices. Basically Inconel 601 Round Bar is a nickel iron chromium alloy with titanium, copper, and molybdenum. Inconel 601 round bar chemical arrangement delivers great performance, whereas Alloy 601 Rod is a mixture of nickel chromium iron alloy and are used in several applications. We also manufacture Inconel 601 Rod in affordable price for our valuable customer.
Inconel 601 Round Bar
Alloy 601 Rod
Inconel 601 flat bar
Alloy 601 Round Bar are standards deliberate while manufacturing these bars. Round bars are mass-produced by a hot rolling process for removing any blow holes confidential the material structures. These are hardboiled by the hardening process, such as Inconel 601 Flat Bar Square, hex, round, rectangle, billet, are shapes of bars. Manufacturers left some acceptances so that can be over later as per supplies.
601 Inconel Alloy Forged Bars and UNS N06601 Inconel Bright Bar are suitable for multiple applications and serve a variability of different industries. These Inconel 601 Forged Bar, 601 Inconel Forged Flat Bars & Inconel Alloy 601 Forged Square Bars and not only these which are mentioned but many more are tend to be stronger than Alloy 601 rolled bars due to the solid center that is provided through the forging process.
Specifications | ASTM B166 / ASTM SB166 |
Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
Size |
5 mm To 500 mm |
Diameter | 0.1 mm to 100 mm |
Length | 100 mm To 3000 mm Long & Above |
Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Inconel 601 Round Bar | Nickel 601 Rod |
Inconel 601 ASTM B166 Bar | ASTM B166 UNS N06601 Flat Bar Black |
Inconel 601 din 2.4851 Rounds | Alloy 601 Flat Bar Bright |
ASTM B166 UNS N06601 Bright Bars | Inconel 601 UNS N06601 Flat Bar Polished |
Nickel 601 Rods | Inconel 601 ASTM B166 Rod Cold Drawn |
Inconel 601 din 2.4851 Square Bar Cold Drawn | Inconel 601 ASTM B166 Bright Bar material |
Alloy 601 Rod | Inconel 601 Flat Bar Annealed |
Inconel 601 UNS N06601 Round Bars | Inconel 601 ASTM B166 Flat Rod |
Nickel Alloy 601 Hex Rod | Inconel 601 din 2.4851 Threaded Bars |
Inconel 601 ASTM B166 Square Bar Polished | Inconel 601 Bright Bars Hot Rolled |
601 Inconel Hex Bar Bright | Nickel 601 Hollow Rod |
Inconel alloy 601 Rectangular Bar Annealed | ASTM B166 UNS N06601 Polished Hex Bar |
Inconel 601 Hex Bar Polished | Alloy 601 Hexagonal Rod |
601 Inconel Rectangular Rod | Nickel Alloy 601 Threaded Bar Black |
ASTM B166 UNS N06601 Hex Bar Annealed | Nickel Alloy 601 Cold Drawn Round Bar |
Alloy 601 Forged Bar | Inconel alloy 601 Polished Rod |
Size & Dimensions of inconel 601 round bar | |||||||
---|---|---|---|---|---|---|---|
Metric | US Bar | ASTM/ Canadian | Japanese | ||||
Bar Size | Diam. (mm) | Bar Size | Diam. (Inch) | Bar Size | Diam. (mm2) | Bar Size | Diam. (mm) |
5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
7 | 7 | #5 | 0.601 | 25M | 500 | 16 | 16 |
8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
12 | 12 | #10 | 1.250 | 32 | 32 | ||
14 | 14 | #11 | 1.375 | 35 | 35 | ||
16 | 16 | #12 | 1.500 | 38 | 38 | ||
18 | 18 | #13 | 1.601 | 41 | 41 | ||
20 | 20 | #14 | 1.750 | 44 | 44 | ||
22 | 22 | #15 | 1.875 | 48 | 48 | ||
25 | 25 | #16 | 2.000 | 51 | 51 | ||
28 | 28 | #18 | 2.250 | 57 | 57 | ||
32 | 32 | ||||||
36 | 36 | ||||||
40 | 40 | ||||||
44 | 44 | ||||||
50 | 50 |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
UNS: |
N06601 |
Specifications: |
ASTM B166, AMS 5715 |
international Specifications: |
DIN 17752, DIN 17753, DIN 17754, EN10095, ISO9723, ISO 9724, ISO 9725, WERKSTOFF Nr 2.4851 |
