As expected of the specification a tension test, as well as a nondestructive ultrasonic test, is performed on each specimen, in this case, the ASTM B564 UNS N08825 Slip On Flange. Often, the Incoloy 825 Flanges are valued for their impressive set of properties which enable them to be used in industries such as chemical and petrochemical, ore processing, petroleum refining, nuclear, offshore oil and gas production, food processing, air pollution control, steel pickling as well as waste disposal industries.
Incoloy 825 Flanges
Alloy 825 Blind Flange
ASTM B564 UNS N08825 Slip On Flange
Since titanium has been incorporated into the alloy used in the production of Incoloy 825 Lap Joint Flange, the alloy is stabilized thus gains the ability to resist sensitization. Therefore, Alloy 825 Blind Flange can be used in an as welded condition, while not being susceptible to attack from intergranular after it has been exposed to elevated temperature settings, especially in that range which would sensitize un-stabilized stainless steel grades. Since the alloy is easily formed and can be welded using any conventional practices, the Alloy 825 Blind Flanges can be welded on the pipe or pressure vessels easily, proving to be a time efficient component.
Inconel 825 Flanges
The corrosion resistance properties of Incoloy 825 Spectacle Blind Flange, especially to chloride stress-related corrosion are attributed to their inheritance from alloyants i.e. - nickel, chromium and molybdenum. While the mechanical properties of alloy 825 are good from cryogenic to moderately high temperatures, exposure of the Incoloy 825 Pipe Flanges at a temperature above 1000°F could result in changes i.e. lowering of properties such as ductility and impact strength.
Standard | ASTM B564 / ASME SB564 |
Size Chart | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 |
---|---|
Standards | API7S-15, API7S-43, API605, ANSI/ASME B16.5, B16.47 Series A & B, B16.48, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, EN1092 |
Pressure Rating ANSI | 600 LBS, 900 LBS, 150 LBS, 2500 LBS, 300 LBS, 1500 LBS |
Pressure Calculation in DIN | 16Bar 6Bar 25Bar 40Bar 10Bar / PN10 PN16 PN6 PN25 PN64 PN40 |
JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
Equipment | Bending machine, Pushing Machine,Press machine, electric bevelling machine, Sand-blasting machine etc |
Origin | Indian / West Europe / Japan / USA / Korean |
Production technique |
|
Coating | Anti-rust Paint, Zinc Plated,Oil Black Paint, Cold and Hot Dip Galvanized, Yellow Transparent |
Most common types | Forged / Threaded / Screwed / Plate |
Connect Type/ Flange Face Type | Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Raised Face (RF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
Special design |
As per your drawing AS, ANSI, BS, DIN and JIS |
Test | Hydrostatic testing machine, X-ray detector, Direct-reading Spectrograph, UI trasonic flaw detector, Magnetic particle detector |
Uses & application |
|
Manufacturer of |
ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc.
|
Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 |
Price of Incoloy 825 Flanges | Nickel 825 Flange Price in India (INR) | Nickel 825 Flange Price in USD | Nickel 825 Flange Price in UAE Dirham |
---|---|---|---|
FLANGES - INCOLOY FLANGES (INC.825) 2 WN 900 RJ SCH XXS | INR 3,385 | $45.18 | 165.93 UAE Dirham |
FLANGES - INCOLOY FLANGES (INC.825) 2 WN 150 RF SCH XXS 63-125 | INR 1,057 | $14.11 | 51.81 UAE Dirham |
FLANGES - INCOLOY FLANGES (INC.825) 2 WN 300 RF SCH XXS 63-125 RMS | INR 1,710 | $22.82 | 83.82 UAE Dirham |
Nominal Size |
Outside Diameter (OD) |
Min. Thickness (T) |
RF Dia. (R) |
No. of Bolt Holes | Diameter of Holes |
Bolt Circle (BC) |
SO Bore ID (SB) |
* WN Bore ID (WB) |
Dia. Hub Base (HB) |
Dia. Hub Top (HT) |
SO LTH (SL) |
WN LTH (WL) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
3 | 9.50 | 1.50 | 5.00 | 8 | 1.00 | 7.50 | 3.57 | * | 5.00 | 3.50 | 2.12 | 4.00 |
4 | 11.50 | 1.75 | 6.19 | 8 | 1.25 | 9.25 | 4.57 | * | 6.25 | 4.50 | 2.75 | 4.50 |
5 | 13.75 | 2.00 | 7.31 | 8 | 1.38 | 11.00 | 5.66 | * | 7.50 | 5.56 | 3.12 | 5.00 |
6 | 15.00 | 2.19 | 8.50 | 12 | 1.25 | 12.50 | 6.72 | * | 9.25 | 6.63 | 3.38 | 5.50 |
8 | 18.50 | 2.50 | 10.63 | 12 | 1.50 | 15.50 | 8.72 | * | 11.75 | 8.63 | 4.00 | 6.38 |
10 | 21.50 | 2.75 | 12.75 | 16 | 1.50 | 18.50 | 10.88 | * | 14.50 | 10.75 | 4.25 | 7.25 |
12 | 24.00 | 3.12 | 15.00 | 20 | 1.50 | 21.00 | 12.88 | * | 16.50 | 12.75 | 4.63 | 7.88 |
14 | 25.25 | 3.38 | 16.25 | 20 | 1.63 | 22.00 | 14.14 | * | 17.75 | 14.00 | 5.12 | 8.38 |
16 | 27.75 | 3.50 | 18.50 | 20 | 1.75 | 24.25 | 16.16 | * | 20.00 | 16.00 | 5.25 | 8.50 |
18 | 31.00 | 4.00 | 21.00 | 20 | 2.00 | 27.00 | 18.18 | * | 22.25 | 18.00 | 6.00 | 9.00 |
20 | 33.75 | 4.25 | 23.00 | 20 | 2.13 | 29.50 | 20.20 | * | 24.50 | 20.00 | 6.25 | 9.75 |
24 | 41.00 | 5.50 | 27.25 | 20 | 2.63 | 35.50 | 24.25 | * | 29.50 | 24.00 | 8.00 | 11.50 |
Incoloy alloy 825 Flange | Incoloy 825 Blind Flange |
Incoloy 825 din 2.4858 Slip on Flange | ASTM B425 UNS N08825 Threaded Flange |
Incoloy alloy 825 Reducing Flange | Incoloy 825 ASTM B425 Socket Weld Flange |
ASTM B425 UNS N08825 Weld Neck Flanges | Incoloy 825 Lap Joint Flanges |
Incoloy 825 UNS N08825 Long Weld Neck Flanges | Incoloy alloy 825 Spectacle Blind Flanges |
ASTM B425 UNS N08825 Spades & Ring Spacers | Incoloy 825 ASTM B425 Nipoflange |
Incoloy 825 5D Weldoflange | Nickel Alloy 825 Flange Outlet |
Incoloy alloy 825 Forged Flanges | Alloy 825 Plate Flange |
Incoloy alloy 825 Ring Type Joint Flanges | Incoloy 825 ASTM B425 Raised Face Flanges |
Incoloy 825 Tongue and Groove Flanges | Alloy 825 Male and Female Flange |
ASTM B425 UNS N08825 Reducing Flanges | Incoloy alloy 825 ASME B16.5 Flanges |
Nickel Alloy 825 Flanges | Incoloy 825 din 2.4858 BS 10 Flanges |
Incoloy 825 BS 4504 Flanges | Incoloy 825 ASTM B425 EN 1092-1 Flanges |
Incoloy 825 UNS N08825 SORF Flange | Incoloy alloy 825 BLRF Flange |
Nickel Alloy 825 WNRF Flange | Incoloy 825 din 2.4858 RTJ Flange |
Incoloy 825 Series a Lap Joint Ring Flange | Incoloy 825 ASTM B425 Class 300 threaded flange |
Incoloy alloy 825 PN16 blind flange | Nickel 825 Forged Socket Weld Pipe Flange |
Incoloy 825 Class 300 slip on flange | ASTM B425 UNS N08825 Slip On Weld Flange |
Incoloy 825 din 2.4858 Forged steel slip on flanges | Incoloy 825 din 2.4858 Race face slip on flange |
Nickel Alloy 825 SWRF Flange | Nickel 825 Forged blind flange |
Incoloy 825 groove weld neck flange | Incoloy 825 UNS N08825 Socket Weld Hub Flange |
Incoloy 825 Slip On Flanges | Incoloy 825 Ring Type Joint Flanges |
Incoloy 825 Weld Neck Flanges | Incoloy 825 Socket Weld Flanges |
Incoloy 825 Blind Flanges | Incoloy Uns N08825 Sorf Flanges |
Incoloy 825 Orifice Flanges | ASTM B564 Uns N08825 Blind Flanges |
Nickel Alloy 825 threaded lap joint flange | Nickel 825 Slip On Integral flange |
Incoloy 825 Forged integral puddle flange | Incoloy 825 din 2.4858 table e long weld neck |
Incoloy alloy 825 Class 150 LBS Flange | Alloy 825 PN10 Forged Flanges |
Incoloy 825 RTJ Flanges | ASTM B425 UNS N08825 PN10 Plate Flanges |
Incoloy alloy 825 Tongue & Groove Flanges | Incoloy 825 Reducing Flanges |
Incoloy 825 din 2.4858 Class 150 reducing threaded flange | Incoloy 825 din 2.4858 Class 150 Pipe Flange |
Incoloy 825 UNS N08825 Class 150 Flange | Nickel 825 Pipe Flanges |
Incoloy alloy 825 BS 10 Flanges | 825 Incoloy Class 150 Tongue & Groove Flanges |
Incoloy 825 din 2.4858 BS 4504 pn16 flange | Incoloy alloy 825 EN 1092-1 flat flange |
Nickel 825 Raised Face Flanges | Incoloy 825 UNS N08825 Flat Faced Plate Flanges |
Incoloy 825 ASTM B425 Bleed Rings | Incoloy alloy 825 Class 150 Weldoflange |
Incoloy 825 din 2.4858 Class 150 LBS Nipo Flange | Incoloy alloy 825 Long Weld Neck Flanges |
Incoloy 825 UNS N08825 Lap Joint Pipe Flanges | Incoloy 825 UNS N08825 PN16 Screwed Flanges |
UNS: |
N08825 |
Specifications: |
ASTM B564/ASME SB564 |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
Density | 8.1 g/cm³ |
Melting range | 1370-1400℃ |
Standard |
Class |
Diameter |
Bolt Circle Diameter |
Number of Bolts |
Bolt Size |
Diameter of Bolt Hole |
---|---|---|---|---|---|---|
AS4087 Flanges |
PN14 Flanges |
120 |
87 |
4 |
M12 |
14 |
AS 2129 Flange
|
Table C Flange |
120 |
87 |
4 |
13 |
14 |
Table D Flange |
120 |
87 |
4 |
13 |
14 |
|
Table E Flange |
120 |
87 |
4 |
13 |
14 |
|
Table F Flange |
135 |
98 |
4 |
16 |
18 |
|
Table H Flange |
135 |
98 |
4 |
16 |
18 |
|
Table J Flange |
135 |
98 |
4 |
16 |
18 |
|
ANSI B16.5 Flanges
|
ANSI 150 Flange |
117 |
89 |
4 |
13 |
16 |
ANSI 300 Flange |
133 |
98 |
4 |
16 |
19 |
|
ANSI 600 Flange |
133 |
98 |
4 |
16 |
19 |
|
ANSI 900 Flange |
159 |
111 |
4 |
22 |
25 |
|
ANSI 1500 Flange |
159 |
111 |
4 |
22 |
25 |
|
ISO 7005 (DIN) Flange
|
PN6 Flange |
120 |
90 |
4 |
M12 |
14 |
PN10 Flange |
140 |
100 |
4 |
M16 |
18 |
|
PN16 Flange |
140 |
100 |
4 |
M16 |
18 |
|
PN20 Flange |
120 |
89 |
4 |
M14 |
16 |
|
PN25 Flange |
140 |
100 |
4 |
M16 |
18 |
|
PN40 Flange |
140 |
100 |
4 |
M16 |
18 |
