We are manufacturer of Incoloy 800 seamless tube this industrial product with some standards because we are major with massive inventory of not only the industrial products which we have deliberated above but we also produce Incoloy 800 seamless tube with some standard and outstanding material under the observation of superior staff, whereas Incoloy 800H tubes are an iron nickel chromium alloy having the same basic arrangement as Incoloy 800, with meaningfully higher creep rupture power. Temporarily, these Incoloy 800HT tubes are also being obtainable from our Tarang Steel in different sizes and shapes to our customers.
Incoloy 800 Seamless tube
Alloy 800H Tubing
Ni 800HT Cold Drawn Tube
Alloy 800H Tubing and 800HT are two individual solid explanation supported for iron-nickel-chromium alloys. They are characteristically offered as one, dual certified alloy, conference the chemical composition necessities of both alloys. Alloy 800H Tubing are nickel iron chromium alloys that provide high strength and exceptional resistance to corrosion and carburization at high temperatures. Incoloy 800 Tubing is an austenitic heat resilient alloy intended for high temperature structural applications. These nickel steel alloys are undistinguishable excluding for the higher level of carbon, these Incoloy 800 tubing are high Pressure tubes is an iron nickel chromium alloy having the same rudimentary composition as Incoloy 800 Cold Rolled Coiled Tubes, with suggestively higher creep rupture strength.
Incoloy 800 Tube
Alloy 800H and HT was envisioned for high temperature physical applications. These Incoloy 800HT Tubes is meant for nursing and upholding the final chemical properties for high temperature strength and resistance to corrosion. Similarly Alloy 800ht Tube are nickel iron chromium alloys with good strength and admirable resistance to corrosion and carburization in high temperature experience. These nickel steel alloys are undistinguishable excepting for the higher level of carbon in alloy 800H/HT and the addition of up to 1.20 percentage aluminum and titanium in alloy 800HT.
Standard |
ASTM, AISI, GB, JIS, customers' requests available |
Size |
Round Tube: OD: 16-119mm or customized |
Thickness |
0.25mm-3.0mm |
Length |
6m or according to customers' request |
Sample |
Free sample is available, but freight should be paid by you |
Tolerance
|
Outer diameter: ±0.2mm Thickness: ±0.05mm Length: ±0.5mm |
Ends |
In plain end or bevelled ends or as your requirements |
Marking | Tubing are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
---|---|
Welding Line Type |
ERW (Electrical Resistance Weld) |
Finishing |
A. Sanded B. Gloss #400,Mirror #600 - #1000 D. Wood Grain C. Brushed E. Embossed, Threaded |
Form | ‘U’ bent, Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Etc |
End | Plain End, Beveled End, Treaded Tube |
Application |
Decorations, constructions, food industry, etc. |
Certification |
ISO, SGS |
Rectangle Pipe Size |
10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
Thickness |
exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
Round Pipe Size |
16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
Square Pipe Size |
17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
Length |
6m or according to customer’s request |
Test |
Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
Equipment |
Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
Outer diameter |
6.35-219mm |
Process method |
Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
Origin |
West Europe / Japanese / Indian / USA / Korean / American / European |
Test Certificates |
Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
Types of Incoloy 800 Tube | Out diameter (OD) | Wall thickness | Length |
---|---|---|---|
NB Sizes (in stock) | 1/8” ~ 8” | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 | Upto 6 Meters |
Incoloy 800 Seamless Tube (Custom Sizes) | 5.0mm ~ 203.2mm | As per requirement | Upto 6 Meters |
Incoloy 800 Welded Tube (in Stock + Custom Sizes) | 5.0mm ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
Price of Incoloy 800 Tube | ASTM B407 Alloy 800 Tubing Price in India (INR) | 1.4876 Alloy 800 Tube Price in USD | Nickel Alloy 800 Tubing Price in UAE Dirham |
---|---|---|---|
WELDED INCOLOY TUBING 9.53 MM X 0.5 MM X 6000 MM INCOLOY 800 | INR 681 | $9.10 | 33.41 UAE Dirham |
WELDED TUBING - INCOLOY 800 9.53MM OD X 0.6MM WALL X 6.1MTRS | INR 1,042 | $13.92 | 51.12 UAE Dirham |
INCOLOY 800 TUBES 15.875MM X 0.9MM X 6MTR | INR 694 | $9.27 | 34.05 UAE Dirham |
INCOLOY ALLOY 800H EXT TUBE PKL SLN ANN 133.0 OD X 8.0 MINWA X 6000 MM CUT | INR 1,354 | $18.09 | 66.43 UAE Dirham |
Inconel 800Ht Electropolished Tubing | Inconel alloy 800H Rectangular Tube |
800 Inconel Square Tubing | Inconel 800Ht Polished Tube |
Inconel 800 ASTM B407 Tubing | Nickel Alloy 800 Fabricated Tube |
Inconel alloy 800H Seamless Tube | ASTM B407 UNS N08800 12mm Tube |
Nickel 800 Welded Tube | ASTM B407 UNS N08800 Seamless Tubing |
Inconel 800Ht High Pressure Tube | Alloy 800H Thin Wall Tubing |
Inconel 800 ASTM B407 Electropolished Tubes | ASTM B407 UNS N08800 Cold Drawn Seamless Tube |
Inconel 800 Hydraulic Tubing | Alloy 800H Coiled Tube |
Nickel Alloy 800 ERW Tube | Nickel 800 Electropolished Tube |
Inconel alloy 800H Rectangular Tubing | 800 Inconel CDW Tube |
ASTM B407 UNS N08800 Electropolish Tube | Inconel 800 Capillary Tubing |
Nickel 800 Small Diameter Tubing | Inconel 800Ht ERW Tubing |
Inconel 800Ht High Pressure Tubing | Inconel 800 ASTM B407 High Pressure Tube |
Inconel 800 Tubing | 800 Inconel Instrumentation tube |
Inconel alloy 800H Tube | 800 Inconel Round Tube |
Nickel 800 EFW Tube | Alloy 800H Finned Tube |
Incoloy NCF 825 Tube | Inconel 825 Electropolish Tube |
Incoloy UNS N08825 Welded Tube | inconel 825 tubing |
825 Inconel Bright Annealed Tube | ASTM B423 Incoloy 825 Tube |
Inconel 825 Decorative Tube | incoloy 825 tubing |
825 Inconel Sanitary Tube | ASTM B705 Incoloy 825 Welded Tubing |
Inconel UNS N08825 Tubing | Inconel 825 Polish Tube |
825 Alloy Tubing | 825 Inconel Heat exchanger Tube |
Inconel WERKSTOFF NR. 2.4858 Tube | 825 Incoloy Alloy Seamless Tubing |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60? | 0.15 – 0.60? |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
UNS: |
N08800 |
Specifications: |
ASTM B407, ASTM B829, ASTM B514, ASTM B775, ASTM B515, ASTM B751 |
international Specifications: |
BS3 3074NA15, ISO 6207, DIN 17459, VdTüV 412 & 434 |
Alloy | Product form | Dimension |
---|---|---|
INCOLOY 800 (32 Ni/21 Cr) | Tube; cold drawn, pickled, annealed | 13.72 x 2.24 mm (¼"nb sch40s) |
INCOLOY 800HT (32 Ni/21 Cr) | Tube; cold drawn, pickled, solution annealed | 60.33 x 2.77 mm (2"nb Sch10s) |
INCOLOY 800HT (32 Ni/21 Cr) | Tube; cold drawn, pickled, solution annealed | 60.33 x 3.91 mm (2"nb sch40s) |
ALLOY 800HT (32 Ni/21 Cr) | Tube; seamless, cold finished, annealed | 48.26 x 3.68 mm (1 ½"nb Sch40s) |
INCOLOY 800 (32 Ni/21 Cr) | Tube; cold drawn, pickled, annealed | 50.8 x 2.64 mm |
INCOLOY 800HT (32 Ni/21 Cr) | Tube; seamless, cold finished, solution annealed | 26.67 x 3.91 mm (¾"nb sch80s) |
INCOLOY 800HT (32 Ni/21 Cr) | Tube; cold drawn, pickled, solution annealed | 33.40 x 3.38 mm (1"nb sch40s) |
ALLOY 800HT (32 Ni/21 Cr) | Tube; seamless, cold finished, annealed | 33.40 x 4.55 mm (1"nb sch80s) |
INCOLOY 800HT (32 Ni/21 Cr) | Tube; cold drawn, pickled, solution annealed | 60.33 x 3.91 mm (2"nb sch40s) |
INCOLOY 800HT (32 Ni/21 Cr) | Tube; cold drawn, pickled, solution annealed | 88.90 x 5.49 mm (3"nb sch40s) |
ALLOY 800HT (32 Ni/21 Cr) | Tube; seamless, hot finished, pickled, passivated | 114.3 x 6.02 mm (4"nb sch40s) |
Types of Incoloy 800 Tube | Out diameter (OD) | Wall thickness | Length |
---|---|---|---|
NB Sizes (in stock) | 1/8” ~ 8” | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 | Upto 6 Meters |
Incoloy 800 Seamless Tube (Custom Sizes) | 5.0mm ~ 203.2mm | As per requirement | Upto 6 Meters |
Incoloy 800 Welded Tube (in Stock + Custom Sizes) | 5.0mm ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
Tube O.D. (in.) |
Wall Thickness of Tube (inches) | |||||||
---|---|---|---|---|---|---|---|---|
.028 | .035 | .049 | .065 | .083 | .095 | .109 | .120 | |
Working Pressure (psig) | ||||||||
1/8 | 7900 | 10100 | ||||||
1/4 | 3700 | 4800 | 7000 | 9500 | ||||
5/16 | 3700 | 5400 | 7300 | |||||
3/8 | 3100 | 4400 | 6100 | |||||
1/2 | 2300 | 3200 | 4400 | |||||
3/4 | 2200 | 3000 | 4000 | 4600 | ||||
1 | 2200 | 2900 | 3400 | 3900 | 4300 |
