Being similar to alloy grade 800, the Incoloy 825 Tee is a fitting that has been titanium stabilized with the addition of copper and molybdenum. Which is why if the two alloys were compared, an elbow constructed from grade Incoloy 825 would exhibit higher resistance to corrosion in aqueous media as opposed to the Alloy 800H/ 800HT Elbow. An important property of the Incoloy UNS N08800 Stub end is that it exhibits good mechanical properties not only at ambient temperature conditions but it also has a good performance at elevated temperature settings, where the temperature can rise as high as 1000°F.
Incoloy 825 Pipe Fittings
ANSI B16.9 Pipe Reducer
Alloy 825 Elbow
This is one reason for which the Incoloy 825 pipe fittings are considered to be a good fit for applications that involve their use in pollution control equipment, oil and gas well piping, nuclear fuel reprocessing, and pickling equipment. Also since the Incoloy 825 Stub End is particularly resistant to both sulfuric acid and phosphoric acid, alloy 825 fittings can be used in applications involving the production of acids as well.
Incoloy 825 Fittings
In addition to having excellent resistance to reducing and oxidizing acid containing environments, the Incoloy 825 Pipe Cap shows resilient to local corrosion attack like crevice corrosion and pitting and can be applied in the chemical processing industry. Due to its impressive host of properties such as durability and excellent resistance to corrosion, the Alloy 825 Elbow has a longer service life than many nickel-based alloys.
Grade | Monel 400 / UNS N04400 |
size | Seamless Butt Weld Fittings: 1/2" - 10" Welded Butt Weld Fittings: 1/2" - 48" |
---|---|
Type | DN15-DN1200 |
Connection | Welding |
Form | 90 Elbow, 45 Elbow, Long Radius Elbow, Short Radius Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Unequal Tee, Lateral Tee, Cross, Bends 1.5d, 3d, 5d, 10d, U bend, 180 Deg Bend, Short Stub End, Long stub end, End Cap, Dish Cap |
Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
Bending Radius | R= 2D, 6D, 1D, 5D, 8D, 3D, 10D or Custom MSS Sp-43 Stainless Steel Pipe Fitting |
Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A403 Stainless Steel Buttweld Fitting |
Manufacturing process | Push, Press, Forge, Cast, etc. |
Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
Key markets and industries |
|
Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Reducers, Pipe Cap, Stub End, Pipe Bend |
Application & uses |
|
We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 |
Price of Incoloy 825 Pipe Fittings | Alloy 825 Butt Weld Fittings Price in India (INR) | ASTM B366 Inconel 825 Pipe Fittings Price in USD | Alloy 825 Butt Weld Pipe Fittings Price in UAE Dirham |
---|---|---|---|
Incoloy UNS N08825 1-1/2" 45deg Elbow | 19871.99 | $286 | UAE Dirham 1050.49 |
825 Incoloy Alloy 1/8" Tee | 13347.59 | $192.1 | UAE Dirham 705.59 |
ASTM B366 825 Incoloy 1/2" Tee | 97761.88 | $1407.2 | UAE Dirham 5167.98 |
Incoloy alloy 825 Fittings | Incoloy 825 Pipe Fitting |
Incoloy 825 din 2.4858 90 Degree Elbow | Incoloy 825 ASTM B366 End Cap |
Nickel 825 45 Degree Elbow | Incoloy 825 UNS N08825 Buttweld Fitting |
Alloy 825 1D Elbow | 825 Incoloy Short Stub End |
Incoloy 825 UNS N08825 Stub End | Incoloy alloy 825 Pipe Cap |
ASTM B366 UNS N08825 3D Elbow | Nickel Alloy 825 End Cap |
Incoloy 825 5D Elbow | Nickel Alloy 825 Reducer |
Incoloy alloy 825 Buttweld Fittings | Incoloy 825 ASTM B366 Pipe Bend |
Nickel 825 Pipe Fittings | Alloy 825 Long Stub End |
Incoloy 825 UNS N08825 Eccentric Reducer | Alloy 825 Long Radius Elbow |
Nickel Alloy 825 Concentric Reducer | Incoloy 825 din 2.4858 Short Radius Elbow |
Nickel 825 Equal Cross | Incoloy alloy 825 Pipe Cap |
Incoloy 825 ASTM B366 Lateral Tee | ASTM B366 UNS N08825 Cross Tee |
Astm B564 Incoloy 825 Forged Threaded Elbow | Incoloy 825 Street Elbow |
Incoloy Din 2.4858 Equal Tees | 825 Incoloy Bushings |
Incoloy 825 Pipe Cap | Standard Size Incoloy 825 Plug |
Asme B16.11 Incoloy 825 Union | 825 Incoloy Tee |
Incoloy Uns N08825 High Pressure Forged Fittings | Incoloy 825 Pipe Nipple |
825 Incoloy Full Couplings | 825 Incoloy Reducing Insert |
825 Incoloy Threaded Fittings | Incoloy 825 Butt Weld Fittings |
825 Incoloy Reducing Cross | Incoloy 825 UNS N08825 Equal Cross |
Incoloy 825 Equal Tee | Nickel Alloy 825 Stub End |
Incoloy 825 ASTM B366 Concentric Reducer | Nickel 825 5D Elbow |
Nominal Pipe Size | Outside diameterat bevel | Center-to-End | |
---|---|---|---|
Run (C) | Outlet(M) | ||
1/2″ | 21.3 | 25 | 25 |
3/4″ | 26.7 | 29 | 29 |
1″ | 33.4 | 38 | 38 |
1 1/4″ | 42.2 | 48 | 48 |
1 1/2″ | 48.3 | 57 | 57 |
2″ | 60.3 | 64 | 64 |
2 1/2″ | 73.0 | 76 | 76 |
3″ | 88.9 | 86 | 86 |
3 1/2″ | 101.6 | 95 | 95 |
4″ | 114.3 | 105 | 105 |
5″ | 141.3 | 124 | 124 |
6″ | 168.3 | 143 | 143 |
8″ | 219.1 | 178 | 178 |
10″ | 273.0 | 216 | 216 |
12″ | 323.8 | 254 | 254 |
14″ | 355.6 | 279 | 279 |
16″ | 406.4 | 305 | 305 |
18″ | 457.0 | 343 | 343 |
20″ | 508.0 | 381 | 381 |
22″ | 559.0 | 419 | 419 |
24″ | 610.0 | 432 | 432 |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
UNS: |
N08825 |
Specifications: |
ASTM B366 |
international Specifications: |
DIN 17744 |
Tensile (ksi) | .2% Yield (ksi) |
---|---|
85 | 30-35 |
Nominal Pipe Size |
Outside Diameter |
Caps | Straight Tees | Straight Crosses | Stub Ends | |||
---|---|---|---|---|---|---|---|---|
(inches)
|
(mm)
|
(inches)
|
Length
(inches) |
Center to End
(inches) |
Center to End
(inches) |
Lap Diameter
(inches) |
Long Length
(inches) |
Short Length
(inches) |
1/2
|
21.3
|
0.840
|
1
|
1
|
–
|
1 3/8
|
3
|
2
|
3/4
|
26.7
|
1.050
|
1
|
1 1/8
|
–
|
1 11/16
|
3
|
2
|
1
|
33.4
|
1.315
|
1 1/2
|
1 1/2
|
1 1/2
|
2
|
4
|
2
|
1 1/4
|
42.2
|
1.660
|
1 1/2
|
1 7/8
|
1 7/8
|
2 1/2
|
4
|
2
|
1 1/2
|
48.3
|
1.900
|
1 1/2
|
2 1/4
|
2 1/4
|
2 7/8
|
4
|
2
|
2
|
60.3
|
2.375
|
1 1/2
|
2 1/2
|
2 1/2
|
3 5/8
|
6
|
2 1/2
|
2 1/2
|
73.0
|
2.875
|
1 1/2
|
3
|
3
|
4 1/8
|
6
|
2 1/2
|
3
|
88.9
|
3.500
|
2
|
3 3/8
|
3 3/8
|
5
|
6
|
2 1/2
|
3 1/2
|
101.6
|
4.000
|
2 1/2
|
3 3/4
|
3 3/4
|
5 1/2
|
6
|
3
|
4
|
114.3
|
4.500
|
2 1/2
|
4 1/8
|
4 1/8
|
6 3/16
|
6
|
3
|
5
|
141.3
|
5.563
|
3
|
4 7/8
|
4 7/8
|
7 5/16
|
8
|
3
|
6
|
168.3
|
6.625
|
3 1/2
|
5 5/8
|
5 5/8
|
8 1/2
|
8
|
3 1/2
|
8
|
219.1
|
8.625
|
4
|
7
|
7
|
10 5/8
|
8
|
4
|
10
|
273.1
|
10.750
|
5
|
8 1/2
|
8 1/2
|
12 3/4
|
10
|
5
|
12
|
323.9
|
12.750
|
6
|
10
|
10
|
15
|
10
|
6
|
